Sun's clad wood sash set fixed lite window has the same frame and sash as our casement but it does not open.
Sun makes two Fixed Lite windows to go with our clad wood products. The two styles have different profiles to coordinate with other products for interior trim applications and visual sight lines.
Our Sash Set Fixed Lite has the same frame and sash as our Casement window but it does not open for ventilation. The daylight opening and sight lines match the Casement.
Our Direct Set Fixed Lite uses only a frame in which the insulated glass is set. This frame gives it a narrow profile to maximize the view opening of the window.
Here is a comparison of our Sash Set Fixed Lite, left side, to our Direct Set Fixed Lite, right side. The wider frame and sash of the Sash Set match our Casement family of products. The narrow frame of our Direct Set is designed to maximize the viewing area of the window.
The standard jamb depth is 4-9/16”. A jamb depth of 6-9/16" is achieved with 2" extensions. Additional jamb options are available. See Jamb Options for more information.
Click on the tabs below to view the various options available for this product.
All of our extruded aluminum-clad windows and doors are available in a wide range of exterior powder-coated finish colors to coordinate with the design of your project. Click on the link below to see our color choices.Exterior Color Options
An extruded aluminum exterior casing and trim system is available on our clad windows and doors to enhance the visual appeal of the windows and doors. Available in a variety of trim and casing profiles, these extrusions add a dimensional accent to the product and the home or building.Exterior Trim Options
Fixed Lites are available in a variety of shapes from Rectangles to Radius, to Geometric shapes.
Our clad-wood products feature clear pine interiors that are ideally suited for staining or painting. Choose to have your windows and doors delivered without any interior finish so that you can stain or paint them yourself or have them primed or painted at the factory with your choice of one of our standard interior finish colors.
The casement window operator is available in two styles and in a selection of finishes.Hardware Options
Sash Set Fixed Lite windows have several jamb options to accommodate the needs of your project. Select the link below to explore our jamb options.Jamb Options
Insulated Glass is the heart of the energy efficiency of windows and patio doors. Sun manufactures our insulated glass units to ensure the quality and performance of our Insulated Glass. Learn more on our Glass Options page.See Glass Options
Quick Links to our Glass Types
Grille systems add divided lite designs to windows and doors. They are available in a variety of patterns that can be customized to meet your design needs.Grille Patterns
Screens are available to help keep insects from entering through a window that is open for ventilation.Screen Options
Content Area 12
Click on the tabs below to view the related technical information.
• Widths: 16”, 20”, 24”, 28”, 30”, 32”, 36”, 40”, 48”, 56”, 64”, 72”
• CS Heights: 16”, 20”, 24”, 28”, 32”, 36”, 40”, 48”, 52”, 59”, 64”, 72”, 78”
• DH Heights: 34-3/16”, 38-3/16”, 46-3/16”, 50-3/16”, 54-3/16”, 62-3/16”, 66-3/16”, 70-3/16”, 74-3/16”
Most of our clad wood products, have a standard jamb depth of 4-9/16”. This is to accommodate typical 2 x 4 wall construction. There are several other jamb options available to address specific applications and construction designs. See our Jamb Options by clicking on the link below.
